Technical Specifications
Processor 1 processor from the following: Intel® Xeon® E-2200 product family, Intel Pentium®, Intel Core i3®, Intel Celeron®
Memory 4 x DDR4 DIMM slots, Supports UDIMM, up to 2666MT/s, 64GB Max. Supports registered ECC
Storage controllers
Internal boot
Internal controllers: PERC H730P, H330, HBA330 (non-RAID)
Software RAID: PERC S140
External HBAs: 12Gbps SAS HBA (non-RAID)
Boot Optimized Storage Subsystem (BOSS): 2 x M.2 240GB (RAID 1 or No RAID) or 1 x M.2 240GB (No RAID only)
Internal Dual SD Module3
: 2x microSD (16GB, 32GB or 64GB) or 1x microSD (16GB, 32GB or 64GB)
Drive bays Up to 8 x 2.5 hot-plug SATA, SAS (optional) or SSD
Up to 4 x 3.5 hot-plug SATA, SAS (optional) or SSD
Power supplies Single or dual 350W (Platinum) or 550W (Platinum) hot-plug redundant power supplies
Dimensions Form factor: Rack (1U) Chassis width: 434.00mm (17.08 in)
Chassis depth: 595.63mm (23.45 in) (3.5” HHD config)
Chassis depth: 544.836mm (21.45 in) (2.5” HHD config)
Note: These dimensions do not include: bezel, redundant PSU
Chassis weight: 13.6 kg (29.98 lb.)
Embedded management iDRAC9 with Lifecycle Controller
iDRAC Direct
iDRAC RESTful API with Redfish
Bezel Optional security bezel
OpenManage™ Software OpenManage Enterprise OpenManage Power Manager
OpenManage Mobile
Integrations and
connections
Integrations:
Microsoft® System Center
VMware® vCenter™
BMC Truesight (available from BMC)
Red Hat Ansible
Connections:
Nagios Core & Nagios XI
Micro Focus Operations Manager i (OMi)
IBM Tivoli Netcool/OMNIbus
Tools iDRAC Service Module
OpenManage Server Administrator
Dell EMC Repository Manager
Dell EMC System Update
Dell EMC Server Update Utility
Dell EMC Update Catalogs
Dell EMC RACADM CLI
IPMI Tool
Security TPM 1.2/2.0 optional
Cryptographically signed firmware
Silicon Root of Trust
Secure Boot
System Lockdown (requires OpenManage Enterprise)
System Erase
I/O & Ports Networking Options:
2 x 1GbE LOM Network Interface Controller (NIC) ports
Front ports:
1x USB 2.0, 1 x IDRAC micro USB 2.0 management port
Rear ports: 2 x USB 3.0, VGA, serial connector
2 x PCIe Gen 3.0 slots:
• One x8 slot low-profile, half-length with x4 slot width
• One x16 slot low-profile/full-height, half-length
with x8 bandwith
Supported operating
systems
Citrix® XenServer®
Microsoft® Windows Server® with Hyper-V (2016 and 2019)
Red Hat® Enterprise Linux
Ubuntu® Server LTS
SUSE® Linux Enterprise Server
VMware® ESXi
For specifications and interoperability details,
see Dell.com/OSsupport.
OEM-ready version
available
From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you.
For more information, visit Dell.com/OEM.
Recommended support ProSupport Plus for critical systems or ProSupport for comprehensive hardware and software support for your PowerEdge solution.
Consulting and deployment offerings are also available. Contact your Dell EMC representative today for more information.
Availability and terms of Dell EMC Services vary by region. For more information, visit Dell.com/ServiceDescriptions.
Memory 4 x DDR4 DIMM slots, Supports UDIMM, up to 2666MT/s, 64GB Max. Supports registered ECC
Storage controllers
Internal boot
Internal controllers: PERC H730P, H330, HBA330 (non-RAID)
Software RAID: PERC S140
External HBAs: 12Gbps SAS HBA (non-RAID)
Boot Optimized Storage Subsystem (BOSS): 2 x M.2 240GB (RAID 1 or No RAID) or 1 x M.2 240GB (No RAID only)
Internal Dual SD Module3
: 2x microSD (16GB, 32GB or 64GB) or 1x microSD (16GB, 32GB or 64GB)
Drive bays Up to 8 x 2.5 hot-plug SATA, SAS (optional) or SSD
Up to 4 x 3.5 hot-plug SATA, SAS (optional) or SSD
Power supplies Single or dual 350W (Platinum) or 550W (Platinum) hot-plug redundant power supplies
Dimensions Form factor: Rack (1U) Chassis width: 434.00mm (17.08 in)
Chassis depth: 595.63mm (23.45 in) (3.5” HHD config)
Chassis depth: 544.836mm (21.45 in) (2.5” HHD config)
Note: These dimensions do not include: bezel, redundant PSU
Chassis weight: 13.6 kg (29.98 lb.)
Embedded management iDRAC9 with Lifecycle Controller
iDRAC Direct
iDRAC RESTful API with Redfish
Bezel Optional security bezel
OpenManage™ Software OpenManage Enterprise OpenManage Power Manager
OpenManage Mobile
Integrations and
connections
Integrations:
Microsoft® System Center
VMware® vCenter™
BMC Truesight (available from BMC)
Red Hat Ansible
Connections:
Nagios Core & Nagios XI
Micro Focus Operations Manager i (OMi)
IBM Tivoli Netcool/OMNIbus
Tools iDRAC Service Module
OpenManage Server Administrator
Dell EMC Repository Manager
Dell EMC System Update
Dell EMC Server Update Utility
Dell EMC Update Catalogs
Dell EMC RACADM CLI
IPMI Tool
Security TPM 1.2/2.0 optional
Cryptographically signed firmware
Silicon Root of Trust
Secure Boot
System Lockdown (requires OpenManage Enterprise)
System Erase
I/O & Ports Networking Options:
2 x 1GbE LOM Network Interface Controller (NIC) ports
Front ports:
1x USB 2.0, 1 x IDRAC micro USB 2.0 management port
Rear ports: 2 x USB 3.0, VGA, serial connector
2 x PCIe Gen 3.0 slots:
• One x8 slot low-profile, half-length with x4 slot width
• One x16 slot low-profile/full-height, half-length
with x8 bandwith
Supported operating
systems
Citrix® XenServer®
Microsoft® Windows Server® with Hyper-V (2016 and 2019)
Red Hat® Enterprise Linux
Ubuntu® Server LTS
SUSE® Linux Enterprise Server
VMware® ESXi
For specifications and interoperability details,
see Dell.com/OSsupport.
OEM-ready version
available
From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you.
For more information, visit Dell.com/OEM.
Recommended support ProSupport Plus for critical systems or ProSupport for comprehensive hardware and software support for your PowerEdge solution.
Consulting and deployment offerings are also available. Contact your Dell EMC representative today for more information.
Availability and terms of Dell EMC Services vary by region. For more information, visit Dell.com/ServiceDescriptions.
